This version is compatible with JenNet on the JN516X range of devices (including encryption and time server support).  This revision 1.5.4RC6 includes the latest fixes and improvements including

JTAG Tools Website

The Infinity Suite contains applications for

1. Boundary Scan Testing
2. APEL scripting language that allows you to script control of the IO Pins in the Boundary Scan chain
3. Programming JN516X devices using JTAG
4. Programming Microchip MX devices even when the device is part of a larger JTAG chain
5. STAPL, SVF Tools

The website contains all downloads and allows you to purchase a license on-line for Infinity APEL and Infinity SCAN.

As well as containing information on each of the Infinity applications, there are example scripts, tutorials and other support material


Infinity Suite LaunchPad

This update includes the following:

1) Infinity Database can now be updated from the Infinity Launchpad.

2) Infinity APEL now supports command line parameters. An array of strings called params will now be available at the start of the script. For example:

PRINT "Testing Command line parameters"
Dim i as integer
PRINT DECV(Length(param))
if Length(param) <> 0 then
    FOR i = 1 to Length(param)
        PRINT param[i-1]
    next
endif

3) BSDL import upgrade to store Boundary SCAN cell types and crashes when importing Freescale bsdl files.

4) Correction to the package creation to avoid crashes when faulty symbols are created.

4) Fixes to APEL Compiler to match the speed/performance of APEL Studio

5) Corrected resetting the TCK speed back to the default speed at the beginning of a script.


Once the latest version of Infinity Suite Launchpad has been installed, then update to the latest software by starting Infinity LaunchPad from your desktop and click 'Update Applications'.

Infinity SCAN provides a powerful JTAG Boundary Scan function, with plug-ins giving full support for production applications. Infinity APEL, with its own Embedded Script language, provides comprehensive functional testing and debugging of boards, including non-JTAG devices.

Infinity SCAN/APEL are installed by from the Infinity Launchpad.

Based in Sheffield, South Yorkshire, Atomic Programming was established in 2003 with the specific intent of developing next-generation Programming Tools. We are now providing an innovative approach to the design & manufacture of Wireless Sensor Network technology and JTAG/In-System programming tools and accessories.

The AP-114 ISP/JTAG Programming System provides a universal tool for embedded and In-System Programming requirements, and together with our Infinity SCAN and APEL software provides a complete solution for your JTAG applications.

The programmer also offers an embedded development platform, which includes support for NXP JN5148 and JN516X low-power Wireless Microcontrollers (both Programming & Debugging).

Working closely with NXP-Jennic, we developed all NXP reference module designs and have we developed the AP-3XX range of Wireless Gateways based on the reference design that was created for Jennic (now NXP).

Atomic Programming provides a full consultancy service for new product development. With over 35 years of experience within the Electronics Industry, specifically Digital Electronics and Embedded Systems Design, and a proven track record of taking concepts to production, we are perfectly placed to assist you with your project development.

Atomic Programming are pleased to announce the latest release of both their Infinity SCAN and Infinity APEL Software.

This update includes the following:

1) SCAN+ Compiler crashing on windows 7 64-bit machines.

2) When training in SCAN+ the last device in the chain was not training reliably.

3) Manually setting the test mode of of a pin on the last device in the chain was also unreliable.

4) APEL 'CHAIN' command now verifies the the actual device chain and compares the ID.

5) Scan chain display in APEL Studio does not clear correctly at the end of debugging.

6) Improved the report generation for the Production Test plugin in SCAN+.

6) APEL language modification to allow a bus name to be passed into a function.

7) BSDL importer parsing has been improved to support broadcom BSDL file annomalies.

To update to the latest software start Infinity LaunchPad from your desktop and click update.

Infinity SCAN provides a powerful JTAG Boundary Scan function, with plug-ins giving full support for production applications. Infinity APEL, with its own Embedded Script language, provides comprehensive functional testing and debugging of boards, including non-JTAG devices.

Infinity SCAN/APEL are installed by from the Infinity Launchpad.

Based in Sheffield, South Yorkshire, Atomic Programming was established in 2003 with the specific intent of developing next-generation Programming Tools. We are now providing an innovative approach to the design & manufacture of Wireless Sensor Network technology and JTAG/In-System programming tools and accessories.

The AP-114 ISP/JTAG Programming System provides a universal tool for embedded and In-System Programming requirements, and together with our Infinity SCAN and APEL software provides a complete solution for your JTAG applications.

The programmer also offers an embedded development platform, which includes support for NXP JN5148 and JN516X low-power Wireless Microcontrollers (both Programming & Debugging).

Working closely with NXP-Jennic, we developed all NXP reference module designs and have we developed the AP-3XX range of Wireless Gateways based on the reference design that was created for Jennic (now NXP).

Atomic Programming provides a full consultancy service for new product development. With over 35 years of experience within the Electronics Industry, specifically Digital Electronics and Embedded Systems Design, and a proven track record of taking concepts to production, we are perfectly placed to assist you with your project development.

1) Improved the Route purge algorithm in the coordinator to speed up the route purging mechanism.

2) Improved the Beacon Calming algorithm to allow larger networks to form.

3) Changed to the timeout mechanism in sleeping end devices to improve current consumption.

4) Modified the source code to allow JenieJenNet end device support on JN5161 devices.

The changes have been fully validated on both JN5148 and JN516* large networks.
